The Roland VC-1-SC is a versatile video converter engineered for professional live production, broadcast, and AV integration. It handles a wide range of video formats while preserving the original image quality, ensuring smooth, artifact-free signals across SDI, HDMI, and analog sources.
Key Features
-
Multi-Format Support – 3G (Level A & B), HD, and SD SDI; HDMI In/Out; RGB/Component In; Composite In.
-
HDCP Compliance – Supports protected HDMI content for secure workflows.
-
Audio Embedding & De-Embedding – Route audio to and from video signals for streamlined production setups.
-
Built-In Frame Synchronizer & Scaler – Compensates for SDI signal attenuation and enables input scaling from analog sources.
-
Advanced Conversion Options – Up/Down/Cross conversion, frame rate conversion, interlaced/progressive conversion, and aspect ratio adjustment.
-
VC-1 RCS Software Control – Manage and configure the device remotely via PC or Mac.
-
High-Quality Video Output – Maintains clean, accurate video with no interlacing artifacts or conversion errors.
Reliable & Professional
The VC-1-SC allows integration of multiple video sources—including SDI cameras, HDMI devices, and analog RGB/component feeds—into a single production workflow. Its built-in scaler and frame synchronizer make it ideal for live events, broadcast studios, and hybrid AV setups where high-quality signal conversion is essential.
With HDCP support, flexible audio routing, and full control via the VC-1 RCS software, the VC-1-SC provides a complete, professional-grade solution for converting, scaling, and synchronizing video across multiple formats.
Input Connectors
-
SDI:
-
BNC ×1 (shared with SDI output)
-
Standards: SMPTE 424M / 425M-AB, 292M, 259M-C
-
HDMI:
-
Type A (19 pins) ×1
-
HDCP supported
-
Note: If an HDCP-protected signal is input, SDI output is disabled
-
RGB/Component:
-
HD DB-15 ×1
-
Signal Levels: Y = 1.0 Vp-p, R/G/B/Pb/Pr = 0.7 Vp-p, H/V = 5 V TTL
-
Impedance: 75 Ω
-
Composite:
-
BNC ×1
-
Signal Levels: Y = 1.0 Vp-p, C = 0.286 V (NTSC), 0.3 V (PAL)
-
Impedance: 75 Ω
-
Analog Audio:
-
RCA pair (L/R) ×1 (shared with Analog Audio Out)
-
Input Level: -6 dBV, Max: +6 dBV
-
Impedance: 22 kΩ
-
Reference:
-
BNC ×1
-
Signal Formats: Black Burst, Bi-level, Tri-level
-
Impedance: 75 Ω
Output Connectors
-
SDI: BNC ×2 (one shared with SDI input), Standards: SMPTE 424M / 425M-AB, 292M, 259M-C
-
HDMI: Type A (19 pins) ×1, HDCP supported
-
Analog Audio: RCA pair (L/R) ×1 (shared with Analog Audio In)
-
Output Level: -6 dBV, Max: +6 dBV
-
Impedance: 2.2 kΩ
Supported Input Formats
SDI
-
Video Resolutions:
-
1080p/i: 60/59.94/50/30/29.97/25/24/23.98 Hz
-
1080PsF: 30/29.97/25/24/23.98 Hz
-
720p: 60/59.94/50/30/29.97/25/24/23.98 Hz
-
720x480i, 720x576i
-
Color: 10-bit YCC 4:2:2
-
Audio: Linear PCM, 24-bit / 48 kHz, 16 channels
-
Note: When frame synchronizer is active, HDMI CH 3–8 and SDI CH 3–16 audio are unavailable
HDMI
-
Video:
-
1080p/i: 60/59.94/50/30/29.97/25/24/23.98 Hz
-
720p: 60/59.94/50/30/29.97/25/24/23.98 Hz
-
480i/p, 576i/p
-
PC Formats: 640×480 → 1920×1200 (various refresh rates; reduced blanking at 1920×1200)
-
Color: 10-bit YCC 4:2:2, 8-bit YCC 4:4:4, 8-bit RGB 4:4:4
-
Audio: Linear PCM, 24-bit / 48 kHz, 8 channels
RGB/Component
-
Video: 1080p/i/23.98PsF, 720p, 480/576i/p, PC formats up to 1920×1200
-
Color: 8-bit / 10-bit depending on input
Composite
Processing Features
-
Audio embed/de-embed: 2 channels
-
Frame synchronizer: Activates on reference signal; HDMI CH 3–8 and SDI CH 3–16 audio unavailable when engaged
-
Resolution conversion: Full / Letterbox / Crop / Dot-by-dot
-
Frame rate conversion: Frame skip/repeat
USB
Power
-
DC 9V (via AC adapter)
-
Operating temperature: 0–40°C (32–104°F)
Physical
-
Dimensions (W×D×H): 5-15/16 × 5-1/8 × 1-3/16 in (150 × 130 × 30 mm)
-
Weight: 1 lb 2 oz (500 g)
