The Canon EOS C400 merges innovation, versatility, and imaging excellence in a compact, ergonomic cinema camera body. Designed for professional filmmakers, the EOS C400 delivers full-frame, high-resolution performance while supporting Super 35mm and Super 16 shooting modes.
Key Features
-
6K Full-Frame Back-Illuminated Stacked CMOS Sensor: Supports Super 35mm and Super 16 formats for maximum flexibility.
-
Triple-Base ISO: 800, 3200, and 12,800 for exceptional low-light performance.
-
Advanced Recording Formats: Internal Cinema RAW Light, XF-AVC, XF-HEVC S, and XF-AVC S for versatile post-production workflows.
-
Built-in Mechanical ND Filters: Quickly adjust exposure without compromising image quality.
-
Dual Pixel CMOS AF II: Improved autofocus for precise, smooth tracking of moving subjects.
-
PL-RF Mount Adapter (Optional): Compatible with Cooke/i Technology lenses for cinematic flexibility.
-
Multiple Interfaces: Timecode, Genlock, return video input, Ethernet, and Wi-Fi for seamless integration with other devices.
-
Compact, Lightweight, Ergonomic Design: Optimized for handheld, gimbal, or studio use.
Why It Stands Out
The EOS C400 offers a perfect balance of form and functionality. Its full-frame 6K sensor, robust recording capabilities, and advanced autofocus make it ideal for high-end cinema production, while its compact body design ensures adaptability across any shooting scenario.
Sensor
-
Type: 35mm full-frame CMOS
-
Total Pixels: ~26.7 MP
-
Effective Pixels: ~19.2 MP
-
ISO Sensitivity: 160–25600 (Extended: 100–102400)
-
Base ISO: 800 / 3200 / 12800 / Auto-change (Canon Log 2/3, RAW)
-
Sensor Modes: Full-frame, Super 35mm Crop, Super 16mm Crop
-
ND Filter: Mechanical ND (2, 4, 6, 8*, 10* stops; *with extender)
Image & Video
-
Gamma: Canon Log 2, Canon Log 3, Canon 709, BT.709 Wide DR, BT.709 Standard, PQ, HLG
-
Frame Rates:
-
6K RAW: 59.94P / 50.00P
-
4.3K RAW: 59.94P / 50.00P
-
4K RAW/XF-AVC/XF-HEVC S/XF-AVC S: 59.94P / 50.00P
-
2K RAW/XF-AVC/XF-HEVC S/XF-AVC S: 59.94P / 50.00P
-
Maximum Frame Rates:
-
Full-frame 6000x3164: 60P
-
Super35mm 4368x2304: 100P, 4096x2160: 120P
-
Super16mm 2184x1152: 180P
-
Color Space: Cinema Gamut, BT.2020, BT.709
-
White Balance: Auto, Sunlight, Tungsten, Manual (2000K–15000K), Settings A/B
-
Dynamic Range: 16 Stops
-
Autofocus: Dual Pixel CMOS AF II
Recording Formats
-
Video: Cinema RAW Light, XF-AVC, HF-HEVC, XF-AVC S
-
Photos: JPEG
-
Audio:
-
Linear PCM 24-bit/48kHz/4ch
-
AAC 16-bit/48kHz/2ch (XF-HEVC S/XF-AVC S)
-
Recording Media: CFexpress, SD Card
Display & Viewfinder
-
LCD: 3.5-inch, 2.76M dots, touch panel
-
Viewfinder: None
-
Multi-function Shoe: Yes (with power contacts)
Connectivity / I/O
-
Lens: Yes
-
SDI Out: BNC ×1 (12G/6G/3G/HD-SDI)
-
Monitor Out: BNC ×1 (3G/HD-SDI)
-
HDMI: Type-A
-
Audio Inputs: Mini-XLR ×2 (AES/EBU not supported)
-
Ethernet: Yes
-
USB: Type-C (smartphone, LCD, grip connection)
-
Mic: 3.5mm stereo mini jack
-
Headphone: Stereo
-
Remote A: 2.5mm REMOTE terminal
-
Remote B (RS-422): No
-
Time Code / G-Lock / Sync / Ret: DIN terminals
-
DC-IN: 12V XLR (4-pin)
Power & Battery
-
Batteries: BP-A30N, BP-A60N
-
DC Input: 12V, 4-pin XLR
-
Operating Temp:
-
Guaranteed performance: ~32–104°F (0–40°C), 85% RH
-
Guaranteed operating: ~23–113°F (-5–45°C), 60% RH
Physical
-
Dimensions (WxHxD): ~5.6 × 5.3 × 5.3" (142 × 135 × 135 mm)
-
Weight (Main Body): ~3.4 lbs (1550 g)
