Designed for uncompromising audio professionals, the ADAM Audio S3V is a high-performance vertical 3-way midfield studio monitor engineered to deliver pristine accuracy, powerful low-end response, and exceptionally detailed imaging. Ideal for critical listening environments, the S3V is a standout choice for mixing, mastering, and sound design in mid-sized control rooms or compact studios requiring top-tier performance.
Key Features:
-
S-ART Tweeter – Handcrafted in Berlin: Each folded-ribbon tweeter is built to the most exacting standards in ADAM Audio’s history, offering unmatched clarity and transient response.
-
4:1 Air Velocity Ratio: The folded S-ART membrane moves air four times faster than the driver itself, ensuring precise high-frequency detail without distortion.
-
Advanced HPS Waveguide: Milled from solid aluminum, the newly designed High-Frequency Propagation System (HPS) provides controlled dispersion and a wide sweet spot.
-
Dome/Cone Hybrid Midrange Driver (DCH): The 4" carbon composite midrange combines the smoothness of a dome driver with the punch of a cone, handling frequencies from 250 Hz to 3 kHz with clarity and presence.
-
9” Extended Linear Excursion (ELE) Woofer: Custom-built with a HexaCone diaphragm and a Symmetrical Magnet Assembly (SMA), this powerful driver produces tight, accurate bass down to 32 Hz.
-
Linear Frequency Response (32 Hz – 50 kHz): Hear every detail across the full frequency spectrum, whether you're working at low or high volumes.
-
Massive Peak SPL ≥ 124 dB per pair: Perfect for dynamic productions that demand headroom and volume without sacrificing definition.
-
Fully Custom DSP Engine: Delivers phase-coherent crossovers, room adaptation, user EQs, delay compensation, and more — all adjustable via USB or software.
-
Triple Amplified System:
-
Woofer: 500W RMS (PWM)
-
Midrange: 300W RMS (PWM)
-
Tweeter: 50W RMS (Class A/B)
-
Connectivity: Analog XLR and AES3 digital input with high headroom and low distortion.
-
Acoustically-Optimized Cabinet: Sturdy, resonance-minimized MDF construction with front-facing bass reflex ports for flexible studio placement.
Technical Specifications:
-
Configuration: Vertical 3-Way Active Studio Monitor
-
Frequency Response: 32 Hz – 50 kHz
-
Max SPL per Pair at 1m: ≥ 124 dB
-
Crossover Frequencies: 250 Hz / 3 kHz
-
Total Harmonic Distortion (THD > 100 Hz): ≤ 0.4%
-
Max Power Consumption: 550 W
-
Weight: 55 lbs (25 kg)
-
Dimensions (HxWxD): 21.1" x 11.5" x 15" (536 x 293 x 380 mm)
Drivers:
-
Woofer:
-
Quantity: 1
-
Size: 9" (223 mm)
-
Voice Coil: 2" (50 mm)
-
Material: HexaCone
-
Midrange:
-
Quantity: 1
-
Type: Dome/Cone Hybrid
-
Size: 4" (100 mm)
-
Voice Coil: 2.4" (60 mm)
-
Material: Carbon Composite
-
Tweeter:
-
Quantity: 1
-
Type: S-ART
-
Diaphragm Area: 4 in² (2420 mm²)
-
Equivalent Diameter: 2" (56 mm)
-
Diaphragm Weight: 0.17 g
-
Waveguide: HPS (High Precision)
Amplification:
-
Woofer Amp: 500W RMS – PWM
-
Midrange Amp: 300W RMS – PWM
-
Tweeter Amp: 50W RMS – Class A/B
Input & DSP:
-
Analog Input: XLR (48 kOhm, +24 dBu max input)
-
Digital Input: AES3
-
User Controls:
-
Input Sensitivity (adjustable)
-
6-band Parametric EQ
-
Low/High Shelf EQ
-
5 Preset Memory Slots
-
Delay: 0–5 ms
-
USB Port for firmware updates and software control
Why Choose the ADAM Audio S3V?
The S3V offers a precise, uncolored monitoring experience for professionals who demand full-range clarity, punch, and tonal balance. Its advanced design delivers mix-ready audio right out of the box, with intelligent DSP tools that adapt to your room — no need for guesswork. Whether you're producing, mixing, or mastering, the S3V ensures every detail is accurately represented, inspiring creative decisions with confidence.
